World Cup
The best for the best.
Developed with the fastest XC riders in the UCI World Cup, the Prototype World Cup is your all out cross country wheelset.
With its hookless full carbon and tubeless ready rim, it is ready for high intensity, aggressive World Cup XC races, providing the best traction and a super accurate driving experience.
Main objective: improve your personal record!
Available colors
HUB Detail
RIM Detail
MSRP: 1.790 €
Vlad Dascalu has proven the quality and reliability of PROTOTYPE products, the world champion jersey is the result …
- World Championship 2019
- European Championship 2019
- National Championship 2019
Performance and reliability are our main concerns.
Products are laboratory tested to the limit, as well as elite athletes who have won over 50 national and international titles.
After a year of exhaustive testing at the XCO World Cup, culminating in Vlad Dascalu World Champion jersey, the World Cup wheels are ready to bring you the best results and feel your bike in a different way.
More rigid, lighter, more accurate and easy to maintain.
These are some EVO4 strengths, the new hub for 2020 was designed and developed specifically for the new World Cup wheels, further enhanced with the redesigned freehub system that can transfer greater pedaling power, resulting in a more direct transmission of power. Oversized bearings and a 17mm axle increase smooth and long-lasting operation maintain lightness, rigidity and durability.
KEY BENEFITS
Use every inch of the track!
Accelerate, corner and sprint faster with lighter, stiffer wheels.
All the details make the difference.
The 27mm inner wide rim offers perfect tire integration and makes the sidewall of the tire more “straight” increasing cornering accuracy.
With 30mm profile, 32mm width, full-carbon rim offers the perfect transfer to the ground of every watt you put on your bike, producing a instant acceleration.
The J-Blend 2.0 aero spokes makes it possible to increase wheel stiffness by 9%, providing excellent performance that will surely surprise you!
SPECIFICATIONS
Rim
- Material: full carbon
- Width (inner/outer): 27/32mm
- Profile: 30mm
- Type: tubeless ready
- Rim shape:asymmetric and hookless
Hub
- Model: EVO 4
- Material: aluminium light-force
- Bearings: sealed – PROTOTYPE PRO 2
- Braking System: IS (6-bolt)
- Clamping: thru-axle
Tire
- Size: 29″
- Type: tubeless or tubeless ready
- Width: 2.0 to 2.5
- Max. Pressure: 60psi /4bar
Spokes and Nipples
- Model: aero 2.0
- Type: J bend
- Spoke material: sandvik
- Nipple material: aluminium
Compatibility Wheel
- Front Wheel
- Caps: 15x110mm (Hub EVO 4)
- Caps: 9x100mm/ 15x100mm (Hub EVO 3.1)
- Hub: Lefty / Lefty Supermax
- Rear Wheel
- Caps: 12x148mm (Hub EVO 4)
- Caps: 10x135mm/ 12x142mm (Hub EVO 3.1)
Options
- Front caps: Fox or Rock Shox
- Freweel body options: Shimano 11, Sram XD or Micro Spline
- Ceramic Bearings: yes
- Color: white or black decal
Wheelset and weight
- Discipline: XC
- ASTM: 3 – ASTM List
- Weight limit: 90kg
- Weight (29″ boost): 1430gr
- Include accessories: user manual, UST Rim tape, aluminium valves
Note: The weights indication is just a reference value.
